Geophysical and core sample data collected offshore Oceanside to San Diego, southern California, during field activity 2018-638-FA from 2018-05-21 to 2018-05-26

By Ray W. Sliter, James E. Conrad, Thomas D. Lorenson, Antoinette G. Papesh, and Jonathan A. Warrick

https://doi.org/10.5066/P9690BEK

Dates

Published: May 26, 2021

Data Collected: May 21, 2018 – May 26, 2018

Summary

The U.S. Geological Survey (USGS) collected geophysical and core sample data aboard the R/V Bold Horizon in 2018 on cruise 2018-638-FA offshore Oceanside to San Diego, southern California. The data were collected to assess sand and gravel resources in Federal and State waters for potential use in future beach nourishment projects along stretches of the coast where critical erosion hotspots have been identified. This cruise was funded through partnerships with the Bureau of Ocean Energy Management (BOEM) and the State of California Ocean Protection Council (OPC).

Sampling Data

  • Core logger data from vibracores collected offshore Oceanside to San Diego, southern California, during field activity 2018-638-FA from 2018-05-22 to 2018-05-26

    This section of the data release contains core logger tabular data of 41 vibracores that were collected aboard the R/V Bold Horizon in 2018 on U.S. Geological Survey Field Activity 2018-638-FA offshore Oceanside to San Diego, southern California. The cores were analyzed for sound velocity (P-wave) and gamma ray density. The logging was performed at 1-cm intervals from the top of each core section. In addition to the core logger data, the location of the cores are available as either a comma-delimited file or a shapefile.

  • Photographs of vibracores collected offshore Oceanside to San Diego, southern California, during field activity 2018-638-FA from 2018-05-22 to 2018-05-26

    This section of the data release contains photographs of 41 vibracores that were collected aboard the R/V Bold Horizon in 2018 on U.S. Geological Survey Field Activity 2018-638-FA offshore Oceanside to San Diego, southern California.

  • Sediment grain size data from vibracore samples collected offshore Oceanside to San Diego, southern California, during field activity 2018-638-FA from 2018-05-22 to 2018-05-26

    This section of the data release contains grain-size and total organic carbon (TOC) analyses of 174 samples taken from vibracores that were collected aboard the R/V Bold Horizon in 2018 on U.S. Geological Survey Field Activity 2018-638-FA offshore Oceanside to San Diego, southern California. The samples were analyzed for percent weight of grain size and total organic carbon. The samples were taken at approx. 50 cm intervals from (and including) the core-catcher, which represents the bottom of the core.

Seismic Data

  • High-resolution, chirp seismic-reflection data collected offshore Oceanside to San Diego, southern California, during field activity 2018-638-FA from 2018-05-21 to 2018-05-26

    This part of the data release contains processed, high-resolution, chirp seismic-reflection profiles that were collected aboard the R/V Bold Horizon in 2018 on U.S. Geological Survey cruise 2018-638-FA offshore Oceanside to San Diego, southern California. Approximately 127 line-kilometers of chirp data were collected offshore Oceanside (BH lines) and 125 line-kilometers were collected offshore Silver Strand, San Diego (SS lines). The data were acquired using an Edgetech 512 Chirp sub-bottom profiling system. These data are divided up and presented by navigation line, as reflected in the individual file names.

    Data Files

    2018-638-FA_chirp_segy.zip - 3.5 GB

    Metadata Files

    2018-638-FA_chirp_metadata.xml - 15.2 KB

    2018-638-FA_chirp_metadata.txt - 14.9 KB

Related Field Activities

  • 2018-638-FA - View Details

    • Suggested Citation

    Sliter, R.W., Conrad, J.E., Lorenson, T.D., Papesh, A.G., and Warrick, J.A., 2021, Geophysical and core sample data collected offshore Oceanside to San Diego, southern California, during field activity 2018-638-FA from 2018-05-21 to 2018-05-26: U.S. Geological Survey data release, https://doi.org/10.5066/P9690BEK.

Study Area

Overview image of data release
Map showing locations of vibracore sites (purple dots) and tracklines (blue) along which chirp seismic data were collected.

Overview Map
