Make A Graph

Dataset Title:	CHINCOTEAGUE - 10181Aysi-a
Institution:	Coastal and Marine Hazards and Resources Program, U.S. Geological Survey (Dataset ID: CHINCOTEAGUE_10181Aysi_a_nc)
Range:	longitude = -75.36831 to -75.36831°E, latitude = 37.867 to 37.867°N, time = 2014-08-15T12:30:51Z to 2014-10-16T18:15:51Z
Information:	Summary \| License \| FGDC \| ISO 19115 \| Metadata \| Background \| Subset \| Data Access Form \| Files

To work correctly, this web page requires that JavaScript be enabled in your browser. Please:
1) Enable JavaScript in your browser:
      • Chrome: "Settings : Advanced : Privacy and security : Site Settings : JavaScript"
      • Firefox: (it should be always on!)"
      • Opera: "Settings : Websites : JavaScript"
      • Safari: "Safari : Preferences : Security : Enable JavaScript"
2) Reload this web page.

Graph Type:

X Axis:

Y Axis:

Color:

Constraints

Optional
Constraint #1

Optional
Constraint #2

Server-side Functions

distinct()

Hover here to see a list of options. Click on an option to select it.

Graph Settings

Marker Type:

Size:

Color:

Color Bar:

Continuity:

Scale:

Minimum:

Maximum:

N Sections:

Draw land mask:

Y Axis Minimum:

Maximum:

(Please be patient. It may take a while to get the data.)

Optional:
Then set the File Type: (File Type information)
and

or view the URL:
(Documentation / Bypass this form

)

Click on the map to specify a new center point.

Zoom:

Time range:

[The graph you specified. Please be patient.]

Things You Can Do With Your Graphs

Well, you can do anything you want with your graphs, of course. But some things you might not have considered are:

Web page authors can embed a graph of the latest data in a web page using HTML <img> tags.
Anyone can use ERDDAPs Slide Sorter to build a personal web page that displays graphs with the latest data (or other images or HTML content), each in its own, draggable slide.

The Dataset Attribute Structure (.das) for this Dataset

Attributes {
 s {
  station_id {
    String actual_range
"CHINCOTEAGUE_10181Aysi_a_nc
CHINCOTEAGUE_10181Aysi_a_nc";
    String cf_role "timeseries_id";
    String ioos_category "Identifier";
    String long_name "Station ID";
  }
  feature_type_instance {
    String ioos_category "Identifier";
    String long_name "Identifier for each feature type instance";
  }
  latitude {
    String _CoordinateAxisType "Lat";
    Float64 actual_range 37.867, 37.867;
    String axis "Y";
    String ioos_category "Location";
    String long_name "sensor latitude";
    String standard_name "latitude";
    String units "degrees_north";
    Float64 valid_max 37.867;
    Float64 valid_min 37.867;
  }
  longitude {
    String _CoordinateAxisType "Lon";
    Float64 actual_range -75.36831, -75.36831;
    String axis "X";
    String ioos_category "Location";
    String long_name "sensor longitude";
    String standard_name "longitude";
    String units "degrees_east";
    Float64 valid_max -75.36831;
    Float64 valid_min -75.36831;
  }
  crs {
    Int32 actual_range -2147483647, -2147483647;
    String epsg_code "EPSG:4326";
    String grid_mapping_name "latitude_longitude";
    Float64 inverse_flattening 298.257223563;
    String ioos_category "Identifier";
    String long_name "http://www.opengis.net/def/crs/EPSG/0/4326";
    Float64 semi_major_axis 6378137.0;
  }
  platform {
    Int32 actual_range -2147483647, -2147483647;
    String definition "http://mmisw.org/ont/ioos/definition/stationID";
    String ioos_category "Identifier";
    String ioos_code "10181Aysi-a";
    String long_name "USGS-CMG time-series data from the Estuarine Physical Response to Storms (EPR), Chincoteague Bay, Maryland/Virginia, 2014-2015 project, mooring 1018 and package 10181Aysi-a. Oceanographic, and water-quality observations made in in Chincoteague Bay, Maryland/Virginia, 2014-2015 to characterize the processes that affect sediment transport to tidal wetlands.";
    String nodc_name "FIXED PLATFORM, MOORINGS";
    String short_name "USGS-CMG time-series data: CHINCOTEAGUE - 1018 - 10181Aysi-a";
    String type "pole mount strapped to piling";
  }
  time {
    UInt32 _ChunkSizes 1000;
    String _CoordinateAxisType "Time";
    Float64 actual_range 1.408105851e+9, 1.413483351e+9;
    String axis "T";
    String calendar "gregorian";
    String ioos_category "Time";
    String long_name "time of measurement";
    String standard_name "time";
    String time_origin "01-JAN-1970 00:00:00";
    String units "seconds since 1970-01-01T00:00:00Z";
  }
  z {
    Float64 actual_range -1.4, -1.4;
    String axis "Z";
    String FillValue "-9999.9";
    String grid_mapping "crs";
    String ioos_category "Other";
    String long_name "z of the sensor relative to the water surface";
    String positive "up";
    String standard_name "height";
    String units "m";
    Float64 valid_max -1.4;
    Float64 valid_min -1.4;
  }
  BPR_1301 {
    UInt32 _ChunkSizes 1000;
    Float64 actual_range 10.5868998234015, 12.4278000206325;
    String ancillary_variables "platform";
    String coordinates "time z latitude longitude";
    String coverage_content_type "physicalMeasurement";
    Int32 epic_code 1301;
    String FillValue "1e+35";
    String grid_mapping "crs";
    String height_depth_units "m";
    Float64 initial_sensor_height 0.5;
    String ioos_category "Other";
    String long_name "Sea Water Pressure";
    Float64 missing_value 1.0e+35;
    String platform "platform";
    Float64 sensor_depth 1.4;
    String serial_number "625";
    String standard_name "sea_water_pressure";
    String units "dbar";
  }
  C_51 {
    UInt32 _ChunkSizes 1000;
    Float64 actual_range 4.004, 5.046;
    String ancillary_variables "platform";
    String coordinates "time z latitude longitude";
    String coverage_content_type "physicalMeasurement";
    Int32 epic_code 51;
    String FillValue "1e+35";
    String grid_mapping "crs";
    String height_depth_units "m";
    Float64 initial_sensor_height 0.5;
    String ioos_category "Other";
    String long_name "Conductivity";
    Float64 missing_value 1.0e+35;
    String note "Use 15pt median filter techinque on C_51 data to eliminate data where > 0.1 units from median filter value, also remove C_51 values < 3.99";
    String platform "platform";
    Float64 sensor_depth 1.4;
    String Sensor_model_number "6560";
    String serial_number "625";
    String standard_name "sea_water_electrical_conductivity";
    String units "S/m";
  }
  DO {
    UInt32 _ChunkSizes 1000;
    Float64 actual_range 0.00439, 0.01159;
    String ancillary_variables "platform";
    String comment "ROX Optical DO sensor, wiped";
    String coordinates "time z latitude longitude";
    String coverage_content_type "physicalMeasurement";
    String FillValue "1e+35";
    String grid_mapping "crs";
    String height_depth_units "m";
    Float64 initial_sensor_height 0.5;
    String ioos_category "Other";
    String long_name "Dissolved oxygen";
    Float64 missing_value 1.0e+35;
    String platform "platform";
    Float64 sensor_depth 1.4;
    String Sensor_model_number "6150";
    String serial_number "625";
    String standard_name "mass_concentration_of_oxygen_in_sea_water";
    String units "kg/m^3";
  }
  D_3 {
    UInt32 _ChunkSizes 1000;
    Float64 actual_range 0.516, 2.36;
    String ancillary_variables "platform";
    String axis "z";
    String coordinates "time z latitude longitude";
    String coverage_content_type "physicalMeasurement";
    Int32 epic_code 3;
    String FillValue "1e+35";
    String grid_mapping "crs";
    String height_depth_units "m";
    Float64 initial_sensor_height 0.5;
    String ioos_category "Other";
    String long_name "Depth";
    Float64 missing_value 1.0e+35;
    String platform "platform";
    String positive "down";
    Float64 sensor_depth 1.4;
    String serial_number "625";
    String standard_name "depth";
    String units "m";
  }
  OST_62 {
    UInt32 _ChunkSizes 1000;
    Float64 actual_range 64.4, 164.0;
    String ancillary_variables "platform";
    String comment "ROX Optical DO sensor, wiped";
    String coordinates "time z latitude longitude";
    String coverage_content_type "physicalMeasurement";
    Int32 epic_code 62;
    String FillValue "1e+35";
    String grid_mapping "crs";
    String height_depth_units "m";
    Float64 initial_sensor_height 0.5;
    String ioos_category "Other";
    String long_name "Dissolved Oxygen (saturation)";
    Float64 missing_value 1.0e+35;
    String platform "platform";
    Float64 sensor_depth 1.4;
    String Sensor_model_number "6150";
    String serial_number "625";
    String standard_name "volume_fraction_of_oxygen_in_sea_water";
    String units "percent";
  }
  P_1ac {
    UInt32 _ChunkSizes 1000;
    Float64 actual_range 0.4095659999807779, 2.2446808333269246;
    String ancillary_variables "platform";
    String coordinates "time z latitude longitude";
    String coverage_content_type "physicalMeasurement";
    String FillValue "1e+35";
    String grid_mapping "crs";
    Float64 initial_instrument_height 0.5;
    String ioos_category "Other";
    String long_name "pressure (corrected for atmospheric)";
    Float64 missing_value 1.0e+35;
    String note "Corrected for variations in atmospheric pressure using record from WAHV2 and weather station at mooring 1031";
    String platform "platform";
    String standard_name "sea_water_pressure_due_to_sea_water";
    String units "dbar";
  }
  S_40 {
    UInt32 _ChunkSizes 1000;
    Float64 actual_range 28.18, 31.34;
    String ancillary_variables "platform";
    String coordinates "time z latitude longitude";
    String coverage_content_type "physicalMeasurement";
    Int32 epic_code 40;
    String FillValue "1e+35";
    String grid_mapping "crs";
    String height_depth_units "m";
    Float64 initial_sensor_height 0.5;
    String ioos_category "Other";
    String long_name "Salinity";
    Float64 missing_value 1.0e+35;
    String note "Use 15pt median filter techinque on S_40 data to eliminate data where > 0.5 units from median filter value, also remove S_40 values  <  28";
    String platform "platform";
    Float64 sensor_depth 1.4;
    String Sensor_model_number "6560";
    String serial_number "625";
    String standard_name "sea_water_practical_salinity";
    String units "1e-3";
  }
  SpC_48 {
    UInt32 _ChunkSizes 1000;
    Float64 actual_range 4.406000000000001, 4.8;
    String ancillary_variables "platform";
    String comment "temperature compensated to 25C";
    String coordinates "time z latitude longitude";
    String coverage_content_type "physicalMeasurement";
    Int32 epic_code 48;
    String FillValue "1e+35";
    String grid_mapping "crs";
    String height_depth_units "m";
    Float64 initial_sensor_height 0.5;
    String ioos_category "Other";
    String long_name "Specific Conductance (conductivity with temperature compensated to 25°C)";
    Float64 missing_value 1.0e+35;
    String note "Use 15pt median filter techinque on SpC_48 data to eliminate data where > 1 units from median filter value, also remove SpC_48 values < 44";
    String platform "platform";
    Float64 sensor_depth 1.4;
    String Sensor_model_number "6560";
    String serial_number "625";
    String standard_name "sea_water_electrical_conductivity";
    String units "S/m";
  }
  T_28 {
    UInt32 _ChunkSizes 1000;
    Float64 actual_range 16.889999999999986, 28.529999999999973;
    String ancillary_variables "platform";
    String comment "ITS-1990 Standard";
    String coordinates "time z latitude longitude";
    String coverage_content_type "physicalMeasurement";
    Int32 epic_code 28;
    String FillValue "1e+35";
    String grid_mapping "crs";
    String height_depth_units "m";
    Float64 initial_sensor_height 0.5;
    String ioos_category "Other";
    String long_name "Water Temperature";
    Float64 missing_value 1.0e+35;
    String platform "platform";
    Float64 sensor_depth 1.4;
    String Sensor_model_number "6560";
    String serial_number "625";
    String standard_name "sea_water_temperature";
    String units "degree_Celsius";
  }
  Turb {
    UInt32 _ChunkSizes 1000;
    Float64 actual_range 2.9, 109.2;
    String ancillary_variables "platform";
    String comment "wiped turbidity probe";
    String coordinates "time z latitude longitude";
    String coverage_content_type "physicalMeasurement";
    Int32 epic_code 980;
    String FillValue "1e+35";
    String grid_mapping "crs";
    String height_depth_units "m";
    Float64 initial_sensor_height 0.5;
    String ioos_category "Other";
    String long_name "Turbidity";
    Float64 missing_value 1.0e+35;
    String note "Recursively filtered Turb data to eliminate data where increases by > 50 units in a single time step";
    String platform "platform";
    Float64 sensor_depth 1.4;
    String Sensor_model_number "6136";
    String serial_number "625";
    String standard_name "sea_water_turbidity";
    String units "NTU";
  }
 }
  NC_GLOBAL {
    String cdm_data_type "TimeSeries";
    String cdm_timeseries_variables "station_id";
    Float64 COMPOSITE 0.0;
    String contributor_name "N. Ganju";
    String contributor_role "principalInvestigator";
    String Conventions "COARDS, CF-1.6, ACDD-1.3";
    String COORD_SYSTEM "GEOGRAPHIC";
    String CREATION_DATE "16-Mar-2016 16:52:04";
    String creator_email "rsignell@usgs.gov";
    String creator_name "Rich Signell";
    String creator_phone "+1 (508) 548-8700";
    String creator_url "https://www.usgs.gov";
    String DATA_ORIGIN "USGS WHCMSC Sed Trans Group";
    String DATA_SUBTYPE "MOORED";
    String date_created "2017-04-11T21:31:00Z";
    String date_issued "2017-04-11T21:31:00Z";
    String date_metadata_modified "2017-04-11T21:31:00Z";
    String date_modified "2017-04-11T21:31:00Z";
    Float64 DELTA_T 900.0;
    String Deployment_date "15-Aug-2014";
    Float64 DEPTH_CONST 0.0;
    String DESCRIPTION "site CB01, Tom's Cove on old USCG pier";
    Float64 DRIFTER 0.0;
    Float64 Easternmost_Easting -75.36831;
    String EXPERIMENT "Estuarine physical response";
    String experiment_name "CHINCOTEAGUE";
    String featureType "TimeSeries";
    Float64 FILL_FLAG 1.0;
    String geospatial_bounds "POINT(-75.36831 37.867)";
    String geospatial_bounds_crs "EPSG:4326";
    Float64 geospatial_lat_max 37.867;
    Float64 geospatial_lat_min 37.867;
    Float64 geospatial_lat_resolution 0;
    String geospatial_lat_units "degrees_north";
    Float64 geospatial_lon_max -75.36831;
    Float64 geospatial_lon_min -75.36831;
    Float64 geospatial_lon_resolution 0;
    String geospatial_lon_units "degrees_east";
    String geospatial_vertical_positive "up";
    String geospatial_vertical_resolution "0";
    String geospatial_vertical_units "meters";
    String grid_mapping_epsg_code "EPSG:4326";
    Float64 grid_mapping_inverse_flattening 298.257223563;
    String grid_mapping_long_name "http://www.opengis.net/def/crs/EPSG/0/4326";
    String grid_mapping_name "latitude_longitude";
    Float64 grid_mapping_semi_major_axis 6378137.0;
    String history
"Fri Nov  1 20:16:47 2019: ncatted -a project,global,a,c,, CMG_Portal CHINCOTEAGUE/10181Aysi-a.nc
Remove obvious spikes/bad data, Trimmed using trunc_cdfNative,  SVN $Revision: 3342 $ to select records in the range 433 to 6408.  :created using ysi2ncNative in Matlab 7.14.0.739 (R2012a).
2017-04-11T21:31:00Z - pyaxiom - File created using pyaxiom
2024-12-12T06:43:00Z (local files)
2024-12-12T06:43:00Z https://cmgds.marine.usgs.gov/tabledap/CHINCOTEAGUE_10181Aysi_a_nc.das";
    String id "10181Aysi-a";
    String infoUrl "https://cmgds.marine.usgs.gov/ocean-time-series/";
    Float64 initial_instrument_height 0.5;
    String INST_TYPE "YSI 6600V2-4";
    String institution "Coastal and Marine Hazards and Resources Program, U.S. Geological Survey";
    String institution_url "https://woodshole.er.usgs.gov";
    String keywords "Earth Science > Oceans > Ocean Pressure > Water Pressure, Earth Science > Oceans > Ocean Temperature > Water Temperature, Earth Science > Oceans > Salinity/Density > Conductivity, Earth Science > Oceans > Salinity/Density > Salinity";
    String keywords_vocabulary "GCMD Science Keywords";
    Float64 latitude 37.867;
    String license
"The data may be used and redistributed for free but is not intended
for legal use, since it may contain inaccuracies. Neither the data
Contributor, ERD, NOAA, nor the United States Government, nor any
of their employees or contractors, makes any warranty, express or
implied, including warranties of merchantability and fitness for a
particular purpose, or assumes any legal liability for the accuracy,
completeness, or usefulness, of this information.";
    Float64 longitude -75.36831;
    Float64 magnetic_variation -11.58;
    Float64 MOORING 1018;
    String naming_authority "gov.usgs.cmgp";
    String ncei_template_version "NCEI_NetCDF_TimeSeries_Orthogonal_Template_v2.0";
    String NCO "netCDF Operators version 4.8.1 (Homepage = http://nco.sf.net, Code = https://github.com/nco/nco)";
    String NCProperties "version=1|netcdflibversion=4.4.1.1|hdf5libversion=1.8.17";
    Float64 Northernmost_Northing 37.867;
    String original_filename "10181Aysi-a.nc";
    String original_folder "CHINCOTEAGUE";
    String platform_type "Pole mount strapped to piling";
    Float64 POS_CONST 0.0;
    String PROJECT "USGS Coastal Marine Geology Program";
    String project "U.S. Geological Survey Oceanographic Time-Series Data, CMG_Portal";
    String project_summary "Oceanographic, and water-quality observations made in in Chincoteague Bay, Maryland/Virginia, 2014-2015 to characterize the processes that affect sediment transport to tidal wetlands.";
    String project_title " Estuarine Physical Response to Storms (EPR), Chincoteague Bay, Maryland/Virginia, 2014-2015";
    String publisher_email "emontgomery@usgs.gov";
    String publisher_name "Ellyn Montgomery";
    String publisher_phone "+1 (508) 548-8700";
    String publisher_url "https://www.usgs.gov";
    String Recovery_date "16-Oct-2014";
    String SciPi "N. Ganju";
    String serial_number "625";
    String source "USGS";
    String sourceUrl "(local files)";
    Float64 Southernmost_Northing 37.867;
    String standard_name_vocabulary "CF-1.6";
    String start_time "15-Aug-2014 12:30:51";
    String stop_time "16-Oct-2014 18:15:51";
    String subsetVariables "station_id";
    String summary "CHINCOTEAGUE - 10181Aysi-a";
    String time_coverage_duration "PT5377500S";
    String time_coverage_end "2014-10-16T18:15:51Z";
    String time_coverage_resolution "PT900S";
    String time_coverage_start "2014-08-15T12:30:51Z";
    String title "CHINCOTEAGUE - 10181Aysi-a";
    String VAR_DESC "Temp C:SpCond mS/cm:Cond mS/cm:Sal ppt:Press psia:Depth meters:Turbid+ NTU:ODO sat %:ODO mg/L:ODO sat_local %:Battery volts";
    Float64 VAR_FILL 1.0e+35;
    Float64 WATER_DEPTH 1.9;
    String WATER_DEPTH_NOTE "(meters), nominal depth";
    String WATER_MASS "Chincoteague Bay, VA/MD";
    Float64 Westernmost_Easting -75.36831;
  }
}

Using tabledap to Request Data and Graphs from Tabular Datasets

tabledap lets you request a data subset, a graph, or a map from a tabular dataset (for example, buoy data), via a specially formed URL. tabledap uses the OPeNDAP (external link)

Data Access Protocol (DAP) (external link)

and its selection constraints (external link)

The URL specifies what you want: the dataset, a description of the graph or the subset of the data, and the file type for the response.

(easy) You can get data by using the dataset's Data Access Form or Subset form. They make the URL for you.
(easy) You can make a graph or map by using the dataset's Make A Graph form. It makes the URL for you.
(not hard) You can bypass the forms and get the data or make a graph or map by generating the URL by hand or with a computer program or script.

Tabledap request URLs must be in the form
https://coastwatch.pfeg.noaa.gov/erddap/tabledap/datasetID.fileType{?query}
For example,
https://coastwatch.pfeg.noaa.gov/erddap/tabledap/pmelTaoDySst.htmlTable?longitude,latitude,time,station,wmo_platform_code,T_25&time>=2015-05-23T12:00:00Z&time<=2015-05-31T12:00:00Z
Thus, the query is often a comma-separated list of desired variable names, followed by a collection of constraints (e.g., variable<value), each preceded by '&' (which is interpreted as "AND").

For details, see the tabledap Documentation.
